Hikmicro Habrok HQ35
|
|
| Thermal Module |
|
| Image Sensor |
Vanadium Oxide Uncooled Focal Plane Arrays |
| Max. Resolution |
640 x 512pixels |
| Frame rate |
50 Hz |
| Pixel interval |
12 μm |
| Response Waveband |
8μm to 14μm |
| NETD |
< 20mk (@25 °C, F#=1.0) |
| Lens (focal length) |
35 mm (F 1.0) |
| Detection range |
1800 m |
| Focus mode |
Focus Ring |
| Field of View (@ 100m) |
12,5° × 10,1° / 22,0m × 17,6m |
| Magnification |
3x - 24x (8x) |
| Optical Module |
|
| Image Sensor |
1.88" Progressive Scan CMOS |
| Max. Resolution |
2560 x 1440 pixels |
| Focal Length |
31mm , F1.2 |
| Min. Working Distance |
3m |
| Min. Illumination |
0.001 lux |
| Magnification |
2,9x - 23,2x (8x) |
| Smart IR |
Yes |
| Viewing Range at Night |
350m |
| Image Display |
|
| Monitor |
0.49-inch, OLED, 1920 ×1080 |
| Palettes |
Thermal: Black hot, white hot, red hot, fusion |
| |
Optical: Day, Night, Auto |
| FFC (Flat Field Correction) Mode |
Auto, Manual, External Correction |
| Exit Pupil |
8 mm |
| Eye Relief |
15 mm |
| System |
|
| Record Video |
Yes |
| Capture Snapshot |
Yes |
| Hotspot |
Yes |
| Standby mode |
Yes |
| Hot Track |
Yes |
| PIP |
Yes |
| GPS |
Yes |
| Digital Magnetic Compass |
Yes |
| Distance measurement |
Yes |
| Power Supply |
|
| Battery Type |
Replacable and rechargeable Li-ion battery |
| Battery Operating Time |
> 6h (25 °C, with hotspot off) |
| Type-C Power Supply |
5 VDC, 2 A, Supports external power supply |
| General |
|
| Working Temperature |
-30°C to +55°C |
| Protection Level |
IP67 |
| Dimension (L x W x H) |
138,2mm × 68,4 mm × 212,4 mm |
| Weight |
780 g (without battery) |
